Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat

Brand Name: Gezhi or OEM
Modelnummer: Mems-1x2
Moq: 1 stuk
Prijs: USD >= 1 pieces $30
Delivery Time: 7 dagen
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Gedetailleerde informatie
Plaats van herkomst:
China
Certificering:
CE RoHS,ISO9001
Toepassing:
5G-optische toegangsnetwerken
Fiberconnector:
LC/UPC, LC/APC, SC/UPC ENZ.
Schakelaartijd:
30 ms
Spanning:
60 V
Haven:
1x2 of 1xN
golflengte:
C-band of Aangepast
Garantietijd:
3 jaar
Verpakking Details:
Inwendige doos, karton
Levering vermogen:
1000 stuks per dag
Markeren:

MEMS-schakelaar met een laag invoegverlies

,

MEMS 1x2 optische schakelaar

,

Epoxyvrije MEMS-schakelaar

Product Description

Productbeschrijving



                                    Laag Invoegverlies Epoxyvrij op optisch pad MEMS 1x2 optisch schakelapparaat

GEZHI Photonics biedt MEMS-optische schakelaars ondersteunen breedbandgolflengte en zijn compact, snel schakelen, hoge stabiliteit en met een hoge kanaalnummer configuratie.,OLM, OTDR of glasvezelsensing enz.



Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 0

Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 1

Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 2Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 3



Kenmerken

Laag invoegverlies
Snelle wisseltijd
Compacte grootte
Meerdere kanalen
Een groot aantal wisselcycli gedurende de levensduur


Toepassingen

Specificaties

  • Optisch netwerk

  • Netwerktestsysteem

  • Bescherming/herstel

  • Bescherming van zender en ontvanger

Parameter
Eenheid
1xN MEMS-optische schakelaar
Golflengtebereik
nm
C-band
L-band
Operatiegolflengte
nm
1530~1570
1570 tot en met 1610
Invoegingsverlies
dB
< 1.0
< 1.0
Terugkeerverlies
dB
≥ 50
Overstroom
dB
≥ 55
Verlies afhankelijk van polarisatie
dB
≤ 0.1
WDL
dB
≤ 0.2
TDL
dB
≤ 0.2
Herhaalbaarheid
dB
≤ ± 0.1
Stroomvoorziening
V
≤ 60
Levensduur
Tijd
≥ 109
Schakeltijd
ms
≤ 30
Optische kracht
mW
≤ 500
Werktemperatuur
°C
-5~+70
Bergingstemperatuur
°C
-40~+85
Afmeting
mm
φ5,5x42
Opmerking: 1. Binnen de werktemperatuur en alle SOP's.
2. Bovenstaande specificatie is geen inlude connector, als je connector toevoegt, zal de IL 0,3 dB toenemen.



Technische parameter

1. Eenmalige modus

Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 4Multi-modus

Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 5

  •

Optische route

mems di.jpg

Afmeting



mems d.jpg



Informatie over bestellingen

Epoxy-vrij op optisch pad MEMS 1x2 optisch schakelaarapparaat 8
